⚙️ Specification
|
Rivet Capacity
|
2.4 ~ 4.8 mm (Steel) / 3/32″ ~ 3/16″ |
|
Traction Power
|
1,219 Kgs (2,680 lbs) |
|
Stroke Length
|
14 mm |
|
Nose Pieces
|
2.4, 3.2, 4.0, 4.8 mm |
|
Avg. Air Cons.
|
3.5 CFM (123 l/min) |
|
Air Pressure
|
60 ~ 100 PSI |
|
Net Weight
|
1.5 Kgs (3.3 lbs) |
|
Overall Length
|
L265 × H275 × D93 mm |
|
Air Inlet
|
1/4″ |
|
Air Hose I.D.
|
3/8″ (10 mm) |
|
Packing
|
10pcs/ctn/1.85cu-ft/GW:19kg |
|
Acceptable rivet material
|
aluminum/steel/stainless |
